Agriculture Equipment Air Filter Exporters – SK-1026AB Excavator air filter element use for 600-181-9500 600-181-9200 600-181-9240 43931922 7000524 3I0935 4137604 TH106445 – Qiangsheng
Agriculture Equipment Air Filter Exporters – SK-1026AB Excavator air filter element use for 600-181-9500 600-181-9200 600-181-9240 43931922 7000524 3I0935 4137604 TH106445 – Qiangsheng Detail:
What are the functions of construction machinery filter elements？
What are the functions of construction machinery filter elements？
The role of construction machinery filter element
The function of the construction machinery filter element is to effectively filter impurities in the oil, reduce the oil flow resistance, ensure lubrication, and minimize the wear of various components during operation; the function of the fuel filter element is to effectively filter the dust, iron filings and metals in the fuel. Oxides, sludge and other impurities can prevent the fuel system from clogging, improve combustion efficiency, and ensure the stable operation of the engine; the air filter element is located in the intake system of the engine, and its main function is to filter out harmful impurities in the air that will enter the cylinder. The early wear of pistons, piston rings, valves and valve seats ensures the normal operation and output power of the engine.
The results show that the wear of the engine mainly includes corrosion wear, contact wear and abrasive wear, and the abrasive wear accounts for 60% to 70% of the wear amount. Construction machinery filter elements usually work in a very harsh environment. If good protection is not formed, the cylinder and piston rings of the engine will wear out quickly. The main function of “three cores” is to reduce the damage of abrasives to the engine by effectively filtering air, oil and fuel, and ensure the efficiency of engine operation.
Replacement cycle of construction machinery filter element
Under normal circumstances, the replacement cycle of the engine oil filter element is 50 hours for the first operation, and then every 300 hours of operation; the replacement cycle for the fuel filter element is 100 hours for the first operation, and then every 300 hours of operation. The difference in the quality grades of oil and fuel can appropriately extend or shorten the replacement cycle; the replacement cycles of construction machinery filter elements and air filter elements used by different models are different, and the replacement cycle of air filter elements is adjusted as appropriate according to the air quality of the operating environment. When replacing, the inner and outer filter elements must be replaced together. It is worth mentioning that the air filter element is not recommended to use data compressed air quality for development and cleaning, because the high-pressure airflow will damage the filter paper and affect the filtration efficiency of the construction machinery filter element.
Product description
SK-1026AB Excavator air filter element use for 600-181-9500 600-181-9200 600-181-9240 43931922 7000524 3I0935 4137604 TH106445
A:
| QS NO. | SK-1026A |
| OEM NO. | KOMATSU 600-181-9500 KOMATSU 600-181-9200 KOMATSU 600-181-9240 VOLVO 43931922 LIEBHERR 7000524 CATERPILLAR 3I0935 HITACHI 4137604 JOHN DEERE TH106445 |
| CROSS REFERENCE | AF4059K AF1733K AF4748K AF25591 P181059 P119136 P105368 P182059 C 16302 |
| APPLICATION | KOMATSU （PC100-3、PC120-3） HITACHI （EX160WD） DAEWOO (DH130、DH130W-V） KATO （HD400SEV、HD400-5、HD450-5、HD400、HD450-7、HD510、HD820) LOVOL （FR75) |
| OUTER DIAMETER | 260 (MM) |
| INNER DIAMETER | 157 (MM) |
| OVERALL HEIGHT | 398/405 (MM) |
B:
| QS NO. | SK-1026B |
| OEM NO. | KOMATSU 600-181-9340 KOMATSU 600-181-9500S CATERPILLAR 3I0065 ISUZU 9142151670 ISUZU 14215167 |
| CROSS REFERENCE | P112212 AF1680 CF923 |
| APPLICATION | KOMATSU （PC100-3、PC120-3） HITACHI （EX160WD） DAEWOO (DH130、DH130W-V） KATO （HD400SEV、HD400-5、HD450-5、HD400、HD450-7、HD510、HD820) LOVOL （FR75) |
| OUTER DIAMETER | 83 (MM) |
| INNER DIAMETER | 54/17 (MM) |
| OVERALL HEIGHT | 329/340 (MM) |
