SY-2175 Excavator hydraulic oil filter B222100000457 for ZOOMLION ZE60/70/80 SANY excavator 55C/60C/65C/75C-9

Short Description:

QS NO.: SY-2175

CROSS REFERENCE: B222100000457

DONALDSON:

FLEETGUARD:

ENGINE: ZOOMLION ZE60/70/80  SANY 55C/60C/65C/75C-9

VEHICLE:  ZOOMLION SANY excavator

LARGEST OD:112(MM)

OVERALL HEIGHT: 437/480 (MM)

INTRNAL DIAMETER: 75  (MM)


Product Detail

Product Tags

Hydraulic Filter Features:

1.We use imported depth type filter material,tapered pore structure,gradient filter,can intercept granule furthest, to extend theservice life.

2.We use high tech support materials.High tech support materials can not only play the role of support filter, material and avoiding compressive deformation,but also protect the materials from being damaged during processing.

3.We also use the special spiral wrapping belts,so thar filter layers can be connected firmly.Stationary pleated distance ensures the uniform flow when fluid penetrating the filter layer.Not only improving pressure drop,but also extending service life.

Function of hydraulic filters

There are many ways to collect contaminants in fluids. An appliance made of filter materials to capture contaminants is called a filter. Magnetic materials are used to adsorb magnetic contaminants called magnetic filters. In addition, there are electrostatic filters, separate filters, etc. In the hydraulic system, all the contaminant particles collected in the fluid are called hydraulic filters. The most widely used hydraulic filters are in addition to the use of porous materials or winding-type slits to intercept pollutants, as well as magnetic filters and electrostatic filters used in hydraulic systems.
After the above-mentioned impurities are mixed into the hydraulic oil, with the circulation of the hydraulic oil, they will cause damage everywhere, which will seriously affect the normal operation of the hydraulic system. Flow small holes and gaps are stuck or blocked; damage the oil film between the relative moving parts, scratch the surface of the gap, increase internal leakage, reduce efficiency, increase heat generation, aggravate the chemical action of the oil, and make the oil deteriorate. According to production statistics, more than 75% of the faults in the hydraulic system are caused by impurities mixed in the hydraulic oil. Therefore, maintaining the cleanliness of the oil and preventing the contamination of the oil are very important for the hydraulic system.
The general hydraulic filter is mainly composed of a filter element (or filter screen) and a shell (or skeleton). Numerous tiny gaps or pores on the filter element constitute the flow area of ​​the oil. Therefore, when the size of the impurities mixed in the oil is larger than these tiny gaps or pores, they will be blocked and filtered out of the oil. Because different hydraulic systems have different requirements, it is impossible to completely filter the impurities mixed into the oil, and sometimes it is not necessary to be demanding.

Product description

QS NO. SY-2175
CROSS REFERENCE B222100000457
DONALDSON
FLEETGUARD
ENGINE ZOOMLION ZE60/70/80  SANY 55C/60C/65C/75C-9
VEHICLE ZOOMLION SANY excavator
LARGEST OD 112(MM)
OVERALL HEIGHT 437/480 (MM)
INTRNAL DIAMETER 75 (MM)
