SY-2359 High quality KOBELCO SK460-8 excavator hydraulic oil return filter element

Short Description:

QS NO.: SY-2359

CROSS REFERENCE:

DONALDSON:

FLEETGUARD:

ENGINE: KOBELCO SK460-8

VEHICLE: KOBELCO excavator hydraulic oil return filter

LARGEST OD: 148(MM)

OVERALL HEIGHT: 377 (MM)

INTRNAL DIAMETER: 100 (MM)


Product Detail

Product Tags

The hydraulic oil return filter element

The hydraulic oil return filter element is specially used to purify and filter impurities in various oil filter systems. Mainly installed in the oil return pipeline, oil suction pipeline, pressure pipeline, separate filter system, etc. Effectively purify the oil to keep each system in the best working condition and prolong the service life of the equipment. The commonly used hydraulic oil filter element adopts the folded wave form, which effectively increases the filtering area and makes the filtering more efficient. Our company can customize super pressure-resistant type, large-flow type, high temperature-resistant type, economical type, etc. according to the needs of various industries.

End cap types: lathe parts, metal stamping parts, rubber injection parts, etc.

Connection Type: Welding, Combination, Adhesive.

Filter material: metal fiber sintered felt, stainless steel filter, multi-layer sintered mesh, stainless steel porous plate, glass fiber filter, chemical fiber filter, wood pulp filter paper.

The hydraulic oil filter element is mainly installed in the hydraulic system: on the oil suction road, on the pressure oil road, on the oil return line, on the bypass, and on a separate filter system.

The hydraulic oil return filter element is mainly made of stainless steel woven mesh, sintered mesh, and iron woven mesh. Since the filter materials it uses are mainly glass fiber filter paper, chemical fiber filter paper, and wood pulp filter paper, it has high concentricity and durability. It has high pressure and good straightness. Its structure is made of single-layer or multi-layer metal mesh and filter material. In specific use, the number of layers and the mesh number of the mesh are determined according to different use conditions and uses.

Product type: hydraulic oil return filter element, transmission filter element

Filter element material: glass fiber, wood pulp paper

Filtration precision: 0.5, 10, 20, 25, 30, 50 microns

Applicable objects: hydraulic oil, lubricating oil, emulsion, high pressure oil,

Working temperature: 50-125(℃)

Product use: oil removal of impurities, purification of oil products

Product description

QS NO. SY-2359
CROSS REFERENCE
DONALDSON
FLEETGUARD
ENGINE KOBELCO SK460-8
VEHICLE KOBELCO excavator hydraulic oil return filter
LARGEST OD 148(MM)
OVERALL HEIGHT 377 (MM)
INTRNAL DIAMETER 100 (MM)
