SY-2006 Heavy Equipment hydraulic oil filter for 07063-01142 PT397 KSH133 195-60-16320

Short Description:

QS NO.: SY-2006

CROSS  REFERENCE: 07063-01142

DONALDSON: P551142

FLEETGUARD: HF6356

ENGINE: PC200-3.PC400-3/6  LS280.E312

VEHICLE: HITACHIEX80 ZHENYU80

LARGEST OD: 150(MM)

OVERALL HEIGHT: 300(MM)

INTRNAL DIAMETER: 110


Product Detail

Product Tags

product features

1.We use imported depth type filter material,tapered pore structure,gradient filter,can intercept granule furthest, to extend theservice life.
2.We use high tech support materials.High tech support materials can not only play the role of support filter, material andavoiding compressive deformation,but also protect the materials from being damaged during processing.
3.We also use the special spiral wrapping belts,so thar filter layers can be connected firmly.Stationary pleated distance ensures

The uniform flow when fluid penetrating the filter layer.Not only improving pressure drop,but also extending service life.

Why Use Hydraulic Filters?

Hydraulic filters are mainly used in varieties of hydraulic system in the industry. These filters have many advantages that ensures safe working of hydraulic system. Some of those advantages of hydraulic oil filters are listed below.
Eliminate the presence of foreign particles in hydraulic fluid
Protect the hydraulic system from the dangers of particle contaminants
Improves the overall efficiency and productivity
Compatible with most of the hydraulic system
Low cost for maintenance
Improves the service life of hydraulic system

How to clean Hydraulic filter?

Many people think that hydraulic oil filter elements are difficult to clean without cleaning, which will greatly reduce the service life of hydraulic oil filter elements. In fact, there are ways to clean the hydraulic oil filter element. Generally, the original hydraulic oil filter element is made of stainless steel wire mesh. To clean such a hydraulic oil filter element, you need to soak the filter element in kerosene for a period of time. It can be easily removed by blowing it out with wind. It’s stained. However, it should be noted that this method cannot be used if it is not for the original hydraulic oil filter element that is too dirty, and it is better to replace it with a new hydraulic oil filter element.

Product description

QS NO. SY-2006
CROSS REFERENCE 07063-01142
DONALDSON P551142
FLEETGUARD HF6356
ENGINE PC200-3.PC400-3/6 LS280.E312
VEHICLE HITACHIEX80 ZHENYU80
LARGEST OD 150(MM)
OVERALL HEIGHT 300(MM)
INTRNAL DIAMETER 110

Our Workshop

workshop
workshop

Packing & Delivery

Packing
Packing

Our Exhibition

workshop

Our service

workshop
